HAVY DUTY PEDESTAL TYPE SPOT WELDING MACHINE

Send Inquiry

Request To Call Back

HAVY DUTY PEDESTAL TYPE SPOT WELDING MACHINE

Name: HAVY DUTY PEDESTAL TYPE SPOT WELDING MACHINE
Brand: PARMO WELDING MACHINES PRIVATE LIMITED
Price: 58000.0 INR
Availability: InStock

Price 58000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

HAVY DUTY PEDESTAL TYPE SPOT WELDING MACHINE Specification

Arc Current
8000-20000 A

Input Current
Max 100 A

Cooling Method
Water Cooling

Type
Pedestal Type Spot Welding Machine

Frequency
50 Hz

Pulse Frequency
Adjustable

Usage
Industrial Welding Applications

Motor Type
Heavy Duty Electromagnet

Insulation Grade
Class F

Welding Area
Steel, Stainless Steel, MS Sheet

Output Current
Max 20000 A

Efficiency
85%

Dimension (L*W*H)
1300 x 600 x 1500 mm

Condition
New

Function
Spot Welding

Weight
350-680 kg

Rod Diameter
12-18 mm

Voltage
415 V

Power
25-75 kVA

Material
Mild Steel

Transformer Type
Copper Wound

Finish
Powder Coated

Electrode Force
300-800 N

Cooling Water Flow
6 L/min

Welding Time Range
0.1-5 sec

Max Welding Thickness
3+3 mm

Electrode Material
Copper Alloy

Protection Class
IP 21

Phase
Three Phase

Throat Depth
250-380 mm

Control Mode
Microprocessor Controlled

Operating Temperature
0°C to 40°C

HAVY DUTY PEDESTAL TYPE SPOT WELDING MACHINE Trade Information

Minimum Order Quantity
1 Number

Payment Terms
Cash Advance (CA)

Supply Ability
2 Per Day

Delivery Time
7 Hours

Sample Policy
Free samples are available

Packaging Details
HAVY BOX PACKING

Main Domestic Market
All India

About HAVY DUTY PEDESTAL TYPE SPOT WELDING MACHINE

HAVY DUTY PEDESTAL TYPE SPOT WELDING MACHINE

Input Power	20 KVA
Usage/Application	Industrial
Type of Spot Welder	Pedal Operated Spot Welder
Dimensions (W x D x H)	142455
Suitable For Welding Rod	2 mm, 3 mm, 4 mm, 1mm
Material	Copper, Metal, Steel, gi, gp
Voltage	415v two phase
Automation Grade	Manual
Phase	3 phase
Frequency	50fz
Rated Input Current	415v
Output Current Range	20kva
Weight	160
Rated Duty Cycle	85%
Throat Depth	18inch
Work Duration	24hours
Cooling Transformer Type	water cooling
Current Control	power and current controller
Brass Steel Thickness	50mm brass road and 18inch
Guaranty	2 year full guaranty
I Deal In	New Only
Country of Origin	Made in India
Minimum Order Quantity	1

KVA Rating	8kva	10kva	12kva	15kva	20kva
Input Supply (V)	220/415	220/415	220/415	220/415	380 / 440
Winding	100% Copper	100% Copper	100% Copper	100% Copper	100% Copper
Phase	single / two	single / two	single / two	single / two	Two Phase
Controlling System	Electronic Timer	Electronic Timer	Electronic Timer	Electronic Timer	Electronic Timer
Brass road (inch)	18inch	18inch	18inch	18inch	16inch
Brass road (mm)	450	450	450	450	400
Brass Road Size (mm)	25 mm	38 mm	38 mm	38 mm	50 mm
Weld Materoal	M.s, S.s, C.r.c, Etc.,	M.s, S.s, G.i, G.l, C.r.c, Brass Etc.,	M.s, S.s, G.i, G.l, C.r.c, Brass Etc.,	M.s, S.s, G.i, G.l, C.r.c, Brass Etc.,	M.s, S.s, G.i, G.l, C.r.c, Brass Etc.,
Copper anode	16mm * 10inch	16mm * 10inch	16mm * 10inch	19mm * 10inch	19mm / 25mm
Suitable For Welding Rod	4mm + 4mm	5mm + 5mm	6mm+6mm	8mm + 8mm	12mm + 12mm
Suitable For Welding Sheet (mm)	0.7 + 0.7	1.2 + 1.2	1.6 + 1.6	2 + 2	3 + 3
Suitable For Welding Sheet	22 gauge	18 gauge	16 gauge	14 gauge	10 gauge
Automation Grade	Manual	Manual	Manual	Manual	Manual
Max. Electrode Stroke(mm)	40	50	50	50	75
Cooling for Arms & Electrods	Air	Air	Air	Air	Air
Weight With arm(Approx)	100	120	130	140	185

Advanced Microprocessor Control

This spot welding machine is equipped with a microprocessor-controlled system, providing precise adjustment for weld timing and current settings. The advanced control technology ensures superior weld quality, repeatability, and user-friendly operation, which is critical for meeting stringent industrial standards across various welding applications.

Robust Construction and Versatility

With a rugged pedestal design using high-quality mild steel and a copper-wound transformer, this machine is built to withstand intensive industrial usage. The heavy-duty copper alloy electrodes and water cooling system enhance performance, making it ideal for continuous spot welding on steel, stainless steel, and mild steel (MS) sheets.

Efficient Cooling and Energy Management

Equipped with a water cooling method (6 L/min flow rate) and an efficiency rating of 85%, this machine prevents overheating, maximizing operational uptime and safety. The system's Class F insulation and IP21 protection class further safeguard both the machine and its operator, enabling optimal productivity in a variety of industrial environments.

FAQ's of HAVY DUTY PEDESTAL TYPE SPOT WELDING MACHINE:

Q: How does the microprocessor control benefit the spot welding process?

A: The integrated microprocessor control offers precise adjustment of welding time and current, resulting in consistent, high-quality welds. This ensures repeatability for various applications and reduces operator error, leading to efficient and accurate spot welding.

Q: What materials can be welded with this pedestal type spot welding machine?

A: This machine is designed to weld steel, stainless steel, and mild steel (MS) sheets up to a maximum thickness of 3+3 mm, making it suitable for a wide range of industrial applications.

Q: Where is this spot welding machine typically used?

A: It is commonly used in industrial workshops, manufacturing units, and fabrication plants where spot welding of sheet metals like steel and stainless steel is required. The machine's robust build and high power make it suitable for heavy-duty welding environments.

Q: What is the process of cooling in this spot welding machine?

A: The machine uses a water cooling system that circulates 6 liters per minute to maintain optimal operating temperatures, preventing overheating during prolonged use and ensuring long-term reliability of components.

Q: When should routine maintenance be performed on this machine?

A: Routine maintenance is recommended after every major production cycle or on a monthly basis, depending on usage intensity. Regular checks of the cooling system, electrodes, and electrical connections help maintain peak performance.

Q: What are the key benefits of using this heavy duty pedestal type spot welding machine?

A: Key benefits include high welding efficiency (85%), robust construction for durability, precise welding control via the microprocessor, and suitability for various sheet metals. Its water-cooled system ensures consistent operation even during extended use.

Q: How is safety ensured during operation?

A: Safety is prioritized with features such as Class F insulation, IP21-rated protection, a powder-coated finish, and stable pedestal structure. These safeguard both the operator and the equipment against electrical and environmental risks.
