spot welding machine

Name: spot welding machine
Brand: PARMO WELDING MACHINES PRIVATE LIMITED
Price: 30000.0 INR
Availability: InStock

Price 30000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

spot welding machine Specification

Function
Manual or Semi-Automatic Spot Welding

Arc Current
Up to 15,000 A

Output Current
Up to 15,000 A

Welding Area
Ferro and Non-Ferro Metals

Motor Type
AC Motor

Cooling Method
Water Cooled

Weight
Approx. 120 kg

Insulation Grade
F

Dimension (L*W*H)
500 mm x 900 mm x 1350 mm

Power
15 KVA

Condition
New

Usage
Industrial, Automotive, Sheet Metal Fabrication

Efficiency
85%

Rod Diameter
Up to 12 mm

Pulse Frequency
Adjustable

Frequency
50 Hz

Input Current
65 A

Voltage
220/415 V

Type
Spot Welding Machine

Material
Mild Steel Body

Display
Digital Panel

Welding Thickness Capacity
0.2 mm to 3 mm

Clamping Force
2.5 kN

Transformer Type
Heavy Duty, Step-down

Surface Finish
Powder Coated

Duty Cycle
50%

Operating Mode
Pedal Operated

Electrode Material
Copper Alloy

Welding Time Range
0-99 cycles

Control System
Microprocessor-based

spot welding machine Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA)

Supply Ability
1 Piece Per Day

Delivery Time
7 Hours

Sample Available
No

Sample Policy
Free samples are available

Packaging Details
havy box packing

Main Domestic Market
All India

About spot welding machine

Type	spot welding machine
Rated Input Power	220v and 440v
Usage/Application	almira, kichan basker, fabrication, fan box, council box, bird cage and many product...
Model Name/Number	8kva copper
Brand	parmo welding machine pvt.ltd.
Material	Steel, Metal, s.s., crc, g.l., g.i
Voltage	220 and 440
Automation Grade	Manual
Phase	singal and tow phase
Frequency	50hz
Rated Input Current	8kva
Weight	100 Aprox
Rated Duty Cycle	heavy duty
Throat Depth	18 inch
Cooling Transformer Type	Air cooling and water cooling
Spot Size	micro
Current Control	thyristor controlling With Timer
Brass Steel Thickness	32mm
Guaranty	1 year
Product Code	8kva copper
Time Control Step	With Timer
Timer Setting Range Weld	micro secound
Transformer Turns Ratio	100% copper
I Deal In	New Only
100% copper winding with heavy duty	Timer With thyristor controlling system

KVA Rating	8kva	10kva	12kva	15kva	20kva
Input Supply (V)	220/415	220/415	220/415	220/415	380 / 440
Winding	100% Copper	100% Copper	100% Copper	100% Copper	100% Copper
Phase	single / two	single / two	single / two	single / two	Two Phase
Controlling System	Electronic Timer	Electronic Timer	Electronic Timer	Electronic Timer	Electronic Timer
Brass road (inch)	18inch	18inch	18inch	18inch	16inch
Brass road (mm)	450	450	450	450	400
Brass Road Size (mm)	25 mm	38 mm	38 mm	38 mm	50 mm
Weld Materoal	M.s, S.s, C.r.c, Etc.,	M.s, S.s, G.i, G.l, C.r.c, Brass Etc.,	M.s, S.s, G.i, G.l, C.r.c, Brass Etc.,	M.s, S.s, G.i, G.l, C.r.c, Brass Etc.,	M.s, S.s, G.i, G.l, C.r.c, Brass Etc.,
Copper anode	16mm * 10inch	16mm * 10inch	16mm * 10inch	19mm * 10inch	19mm / 25mm
Suitable For Welding Rod	4mm + 4mm	5mm + 5mm	6mm+6mm	8mm + 8mm	12mm + 12mm
Suitable For Welding Sheet (mm)	0.7 + 0.7	1.2 + 1.2	1.6 + 1.6	2 + 2	3 + 3
Suitable For Welding Sheet	22 gauge	18 gauge	16 gauge	14 gauge	10 gauge
Automation Grade	Manual	Manual	Manual	Manual	Manual
Max. Electrode Stroke(mm)	40	50	50	50	75
Cooling for Arms & Electrods	Air	Air	Air	Air	Air
Weight With arm(Approx)	100	120	130	140	185

Advanced Control and Flexibility

This spot welding machine is equipped with a microprocessor-based control system, providing precise digital adjustment of welding parameters. The digital panel enables easy monitoring and fine-tuning of settings, while the pedal-operated mode ensures hands-free operation. Adjustable welding time (0-99 cycles) and pulse frequency make it adaptable to varied materials and thicknesses, supporting both manual and semi-automatic spot welding applications.

Built for Performance and Durability

Constructed with a powder-coated mild steel body and a water-cooled system, this machine is built to last in demanding environments. The copper alloy electrodes ensure efficient conductivity and longevity. With a powerful heavy-duty transformer, 50% duty cycle, and an output current of up to 15,000 A, it efficiently welds materials up to 3 mm thick and rod diameters up to 12 mm. Ideal for continuous industrial use with 85% efficiency.

Versatile Industrial Applications

Designed for use in automotive manufacturing, sheet metal fabrication, and general industrial settings, this spot welding machine accommodates both ferro and non-ferro metals. Its flexibility in handling various material types and thicknesses makes it a valuable addition for exporters, manufacturers, and suppliers across India. The system's robust construction and precise control also enhance productivity and weld quality.

FAQ's of spot welding machine:

Q: How does the pedal-operated mechanism work on this spot welding machine?

A: The pedal-operated mechanism allows users to initiate the welding process hands-free by pressing the foot pedal. This enhances operational control and safety, enabling the operator to position the workpiece securely before triggering the weld.

Q: What materials and thicknesses can be welded with this machine?

A: This machine effectively welds both ferro and non-ferro metals, such as steel, stainless steel, and certain non-ferrous alloys. Supported welding thickness ranges from 0.2 mm to 3 mm, and it can handle rod diameters of up to 12 mm.

Q: When should I adjust the welding time or pulse frequency?

A: Welding time (0-99 cycles) and pulse frequency are adjustable to match material type, thickness, and desired weld strength. Adjust these parameters when switching between different metals or thicknesses to ensure optimal weld quality and prevent overheating.

Q: Where is this spot welding machine commonly utilized?

A: This spot welding machine is widely used in industrial sectors, including automotive manufacturing, sheet metal fabrication, and heavy-duty industrial assembly. Its versatile capabilities and robust build make it suitable for both large-scale and specialized welding tasks.

Q: What benefits does the copper alloy electrode provide?

A: Copper alloy electrodes offer excellent electrical and thermal conductivity, ensuring efficient heat transfer and longer electrode lifespan. This contributes to consistent welds and lower maintenance requirements.

Q: How do I ensure the machine operates efficiently and safely?

A: Maintain the recommended duty cycle (50%) and allow proper cooling between cycles using the built-in water-cooled system. Regularly inspect connections and electrodes, and utilize the microprocessor controls for precise parameter adjustments to maximize safety and efficiency.

Q: What are the main advantages of the microprocessor-based control system?

A: The microprocessor-based control system enables precise adjustment of welding parameters and automatic consistency in weld quality. This helps reduce error rates, simplifies operation, and enhances overall productivity in an industrial setting.
